Overview
1x 2 Blockless Fiber PLC Splitter, Singlemode, 900μm Fiber, SC/APC Connector, Planar lightwave circuit (PLC) splitter is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.
Blockless PLC splitter has stronger fiber protection than bare fiber splitter, which is a miniaturization result of cassette splitter. It’s mainly used for various connection and distribution boxes or network cabinets.
PLC Splitter 1×2 Blockless with micro-package and SMF-28e single fiber terminal, tail length according to client’s specified. PLC Splitter 1×2 featured low IL& PDL, high isolation suit for 1260nm~1650nm optical fiber signals’ splitter and distributing in PON networks. PLC Splitter 1×2 Blockless with one input and 2 output. Fiber Optic Splitter 1×4 is a kind of ODN product suitable for PON networks that can be installed in the pigtail cassette, test instrument and WDM system, which minimizes the space occupation. It is relatively fragile on fiber protection and need a complete protection design on carrying box body and device.
Characteristics
- Wavelength: 1260nm / 1650nm
- Minimum Bend Radius: 10mm – allows for tighter bending in cable routing.
- Plug and Play Ready
- Low Insertion Loss
- Low Polarization Dependent Loss
- Good channel-to-channel uniformity
- Excellent Environmental Stability
- Telcordia GR-1221 and GR-1209
- Excellent Mechanical Stability
Specifications
| Parameters | Value |
|---|---|
| Configuration Type | 1×2 |
| PLC Splitter Type | Blockless, ABS type, Cassette, Rack Mount, Bare Fiber |
| Connector Type | SC/APC |
| Fiber Type | Singlemode G657A1 or G652D |
| Fiber Length | 1m or 1.5m or Requested |
| Package Style | Blockless Steel Tube |
| Operating Bandwidth | 1260~1650nm |
| Fiber Diameter | 0.9mm |
| Typical Insertion Loss (≤) dB | 3.9 |
| Insertion Loss (≤) dB | 4.2 |
| Loss Uniformity (≤) dB | 0.4 |
| Polarization Dependent Loss (≤) dB | 0.2 |
| Wavelength Dependent Loss (≤) dB | 0.3 |
| Return Loss (≥) dB | 50 |
| Directivity (≥) dB | 55 |
| Temperature Dependent Loss (≤) dB | 0.5 |
Applications
- Fiber to The Point (FTTX)
- Fiber to The Home (FTTH)
- Passive Optical Networks (PON)
- Gigabit Passive Optical Networks (GPON)
- Local Area Networks (LAN)
- Cable Television (CATV)
- Test Equipment
