Features
- ABS material used ensures the body strong and light.
- Water-proof design for outdoor uses.
- Protection Level: IP55.
- Easy installations: Ready for wall mount – installation kits provided
- Adapter slots used – No screws and tools needed for installing adapters.
- Ready for splitters: designed space for adding splitters.
- Space saving! Double-layer design for easier installation and maintenances:
- Lower layer for splitters and over length fiber storage.
- Upper layer for splicing, cross-connecting and fiber distribution.
- Cable fixing units provided for fixing the outdoor optical cable.
- Accommodates both cable glands as well as tie-wraps
- Lock provided for extra security
Specification
| Product | 48 Ports Wall Mounted Outdoor Fiber Distribution Box |
|---|---|
| Material | ABS |
| IP Protection | IP65 |
| Max. Capacity of Fiber | 2 Fibers |
| No. of Adapter/Port | 2 |
| Suitable Adapter | SC |
| Accommodate Product | 48pcs fiber optic pigtails |
| Inlet Port Diameter | Ф3mm |
| Outlet Port Diameter | Ф7-Ф12mm |
| Installation Type | Wall mount |
| Dimensions (HxWxD) | 410*290*125 mm |
| Weight (g) | 2600g |
