Technical Data：
| Clamp Type | Cable Diameter,mm | Materials | Min Breaking Load,KN | Bail length,mm | Packaging |
| PA2000 | 12-16 | PA66, Stainless steel wire | 10 | 300 | 47*31*35cm,33pcs/carton |
Application
- These clamps will be used as cable dead-end at end poles (using one clamp).
- Two clamps can be installed as double dead-end in the following cases :
- jointing polesat intermediate angle poles when the cable route deviates by more than 20°.
- intermediate poles when the two spans are different in lengths
- intermediate poles on hilly landscapes
Features
- Opening bail and unlosable easy to be installed.
- Good resistance to the cable oscillations thanks to the flexible stainless steel bail.
- Maximum strength load up to 10kn according to the cable used, climatic conditions and installation parameters.
- Self-adjustable wedge.
- High strength PA66, stainless steel bail.
- Long service life.
- Competitive tension clamp price.
- Fast produce.
- Stainless steel bail length is adjustable.
Aerial networks are subject to repetitive climatic stress during several decades. The optical cable and its accessories, in particular the anchoring and suspension clamps, constitute an interdependent component of the complete system that must withstand during its all live time to the various loads induced by wind pressure, ice sleeve weight, Aeolian vibrations, temperature variations, and be resistant to corrosion, UV radiation.
The choice of accessories duly compatible with the cable and the use made of it is essential for a quick and safe installation, to facilitate the operation and ensure a long-term reliability of the network.
