Stock & Custom Fiber Distribution Box Supplier
Bativ is your resource to various Fiber Distribution Box, You will get strong support regardless OEM or ODM to better perform your projects.
Factory Price
14 Years Experience
Quality Assurance
* Free sample is available.
Trusted by Big brands since 2010
Fiber Distribution Box for Options
One-stop Fiber Distribution Box supplier from custom to delivery, Easy and safe, No Overpaying, Fast Delivery.
Single Fiber Fiber Distribution Box
2 Ports Fiber Distribution Box
4 Ports Fiber Distribution Box
6 Ports Fiber Distribution Box
8 Ports Fiber Distribution Box
12 Ports Fiber Distribution Box
16 Ports Fiber Distribution Box
24 Ports Fiber Distribution Box
48 Ports Fiber Distribution Box
Rack Mount Fiber Distribution Box
Wall Mounted Fiber Distribution Box
Get More Fiber Distribution Boxes from Catalog
Check Lastest Fiber Distribution Boxes with price list, Then you can have a helpful benchmark for your procurements. For more assistance, You can contact us directly.
How to Choose Fiber Distribution Box?
We are a fiber connectivity-based company that takes pride in our superior customer service, sending you the best Fiber Distribution Boxes to your doorstep.
1
Fiber Capacity and Fiber Ports
That is how many fiber counts would be spliced or connected into this Fiber Distribution Box.
2
Installation Environment
Assess whether the termination box will be installed indoors, outdoors, in a wall-mount, rack-mount, or pole-mount configuration
3
Connector Types
Usually for FTTx Cabling, SC LC fiber connectivity is popular, But you should also understand it if you have special request.
4
Splicing or Connecting Options
To splice fiber pigtails with cable directly or connected them with fiber optic splitters.
5
Cost and Budget
Here in Bativ, We are supporting you with good quality Fiber Distribution Box at low cost, You can contact us any time to discuss with.
What we care about?
Premium Material
Understand your installation environment with premium ABS material
Useful Accessories
All Fiber Distribution Boxes should be coming with
LOGO Printed
You can put on your logo on any of the Fiber Optic Distribution Box for branding in our markets
Smart Design
Good design makes your installation cost effective and easy to use
Fast Delivery
Usually there are some amount of them are in stock for your urgent need.
Robust Packing & Labeling
Make sure you can receive all freight as good as possible, and easy to check them at your warehouse any time.
What is more?
Custom or wholesale Fiber Optic Distribution Boxes at low cost, 100% of good quality with 540 days warranty.
Your Fiber Optic Distribution Boxes Supplier in China
Bativ is your one-stop supplier for all custom & urgent need fiber distribution box solutions. There are many options for your projects, such as 2 cores, 4 cores to 72 ports, Indoor or outdoor use, Rack mount and wall mount, With us, You not merely get more than a Fiber Distribution Box but a whole solution.
Packaging & Shipping
When we pack your Fiber Distribution Boxes, Each of them are in one inner carton and 20 to 40 inner carton into an outer carton. The most important thing is to keep your package safe.
FAQs
What is a Fiber Optic Distribution Box ?
Fiber Distribution Box is an interface between the fiber cable from the line side and the pigtails to be passed to the fiber distribution frame. A fiber pigtail is a specific hardware connection used for cable termination.
Thus, a Fiber Distribution Box is used to terminate the optical fiber cables in the field and connect them to the pigtail by splicing. After an optical cable arrives at the user’s end, it is fixed in the terminal box. Then, the optical cable core and pigtail are welded in the terminal box.
What are the types of Fiber Optic Distribution Box?
Optical fiber terminal boxes can be of many different types:
Based on Cable Connection Method
- Straight-through Terminal Box: This terminal box has a single external hole for the receiving line.
- Branched-type Terminal Box: This terminal box has several holes for the receiving line.
Based on the number of fibers fused
A terminal box can be divided into 2 in, 8 out, 4 in 24 out, 4 in 12 out, etc.
Based on the shell material
The terminal boxes can be plastic shell or metal shell optical fiber terminal boxes.
Based on the style
These boxes can be rack-drawer, wall-mounted, desktop-type, and other types.
Indoor Fiber Distribution Box
The indoor fiber distribution terminal is a compact fiber box solution for installation requirements in small to mid-sized MDUs, multiple dwelling units, or multiple tenant units (MTU).
Outdoor Fiber Distribution Box
Outdoor Fiber Distribution Terminals are used for installing fiber in small and medium-sized MDUs, or multi-dwelling units.
How to customize a Fiber Optic Distribution Box?
Custom a Fiber Optic Distribution Box is easy here with Bativ, You need to make clear your requirements, We will send you our draft for the custom fiber optic products, Take 2 ports fiber distribution box for example, We can make a 3D model for your reference until you are satisfied with it, Then we can get back to you with our best quote or sample for your quality evaluation.
How to use a Fiber Optic Distribution Box?
Installation of the Fiber Distribution Box must be done under the supervision of a skilled technician or engineer. Here are the various stages in the installation of the FTB.
Mounting
The optical Fiber Distribution Box is mounted on the wall or on the 19 inches (483 mm) wide standard rack. The front panel should be easily accessible as the cable enters from the bottom.
Cable End Preparation
Any fiber cable’s end has to be prepared before starting the cable entry in the optical Fiber Distribution Box. The cable end preparation procedure is available from the supplier. It is crucial to protect the bare fibers at this stage. This is because they get exposed after following the cable end preparation.
Cable Entry
Once the cable ends are prepared, a rubber diaphragm at the box’s cable entry hole needs to be pierced. This is to be done before inserting the cable in the box, as this opening is blocked in new boxes.
Cable End Clamping
The Fiber Distribution Box has several plastic fiber guide posts mounted in it. The fiber in the sleeves or transport tube of the cable is routed through them. Through these guideposts, all the excess length of the cable is brought into the selected splice tray. Then, using a plastic clamping strap, it is clamped at the splice tray’s entry point.
Splicing
The most important part of the installation process is splicing the optical fiber from the cable to the pigtails. A splicing machine is used for this purpose. It is kept close to the termination box on a table.
A stainless steel wire mechanism is released from its spring catch to open a particular splice tray. A splicing machine is used to splice the pigtail fibers so that the fiber ends come out of the cable. They are then pushed to fit into the fused splice.
The process is carried on for all the splices to be stored in splice trays. These splice trays are then placed in a stack inside the termination box. The stainless steel wire closing mechanism is then closed with the box.
What is the MOQ and lead time for your custom Fiber Optic Distribution Box?
It depends on the quantity you will order, Usually 1-3 days for 1000pcs, and 7-10 days for 1000-20000pcs. And 10-15 days for 20000 to 200,000pcs.
Can I get a FREE sample of Fiber Optic Distribution Box?
Free sample is available any time, We believe it will be a good start between us when you tested our fiber patch cable samples.
Send Inquiry Now
Bativ Services Always Go Extra Mile
OEM & ODM Available
Whether you want to have your logo on package or want to custom it differently, we can help you.
Lighting Fast Delivery
If you are no in need of special fiber optic products, just the finished product, The inventory will be of fast delivery.
Start With Low MOQ
If you want to wholesale fiber optic products, we support a minimum order quantity of 1 pcs for the first order.
